Rigol DS1074Z Plus Programming Guide

Chapter 2 Command System RIGOL
MSO1000Z/DS1000Z Programming Guide 2-49
:DECoder<n>:IIC:ADDRess
Syntax
:DECoder<n>:IIC:ADDRess <addr>
:DECoder<n>:IIC:ADDRess?
Description
Set or query the address mode of I2C decoding.
Parameter
Name
Type
Range
Default
<n>
Discrete
{1|2}
--
<addr>
Discrete
{NORMal|RW}
NORMal
Explanation
 NORMal: the address bits (:TRIGger:IIC:AWIDth) does not include the R/W bit.
 RW: the address bits (:TRIGger:IIC:AWIDth) includes the R/W bit.
Return
Format
The query returns NORM or RW.
Example
:DECoder1:IIC:ADDRess RW /*Set the address of I2C decoding to include the R/W
bit*/
:DECoder1:IIC:ADDRess? /*The query returns RW*/

Rigol DS1074Z Plus Specifications

General

Type	Tabletop
Product type	-
Certification	UL 61010-1:2004; CAN/CSA-C22.2 NO. 61010-1-2004; EN 61010-1:2001; IEC 61010-1:2001
Bandwidth	70 MHz
Sampling rate	- MS/s
Channels quantity	4 channels
Minimum time base setting (per division)	5 ns
Power consumption (max)	50 W
Display diagonal	7 \
Non-operating altitude	3000 - 15000 m
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 50 °C

Weight and Dimensions

Depth	122.4 mm
Width	313.1 mm
Height	160.8 mm
