Chapter 2 Command System RIGOL
MSO1000Z/DS1000Z Programming Guide 2-191
:TRIGger:WINDows:ALEVel
Syntax
:TRIGger:WINDows:ALEVel <level>
:TRIGger:WINDows:ALEVel?
Description
Set or query the trigger level upper limit in windows trigger. The unit is the same as the
current amplitude unit.
Parameter
Name
Type
Range
Default
<level>
Real
(-5 x VerticalScale - OFFSet) to
(5 x VerticalScale - OFFSet)
2V
Explanation
For VerticalScale, refer to :CHANnel<n>:SCALe. For OFFSet, refer
to :CHANnel<n>:OFFSet.
Return
Format
The query returns the trigger level upper limit in scientific notation.
Example
:TRIGger:WINDows:ALEVel 0.16 /*Set the trigger level upper limit to 160mV*/
:TRIGger:WINDows:ALEVel? /*The query returns 1.600000e-01*/
:TRIGger:WINDows:BLEVel
Syntax
:TRIGger:WINDows:BLEVel <level>
:TRIGger:WINDows:BLEVel?
Description
Set or query the tigger level lower limit in windows trigger. The unit is the same as the
current amplitude unit.
Parameter
Name
Type
Range
Default
<level>
Real
(-5 x VerticalScale - OFFSet) to
(5 x VerticalScale - OFFSet)
0
Explanation
For VerticalScale, refer to :CHANnel<n>:SCALe. For OFFSet, refer
to :CHANnel<n>:OFFSet.
Return
Format
The query returns the tigger level lower limit in scientific notation.
Example
:TRIGger:WINDows:BLEVel 0.05 /*Set the tigger level lower limit to 50mV*/
:TRIGger:WINDows:BLEVel? /*The query returns 5.000000e-02*/
