RIGOL Chapter 2 Command System
2-190 MSO1000Z/DS1000Z Programming Guide
:TRIGger:WINDows:POSition
Syntax
:TRIGger:WINDows:POSition <pos>
:TRIGger:WINDows:POSition?
Description
Set or query the trigger position in windows trigger.
Parameter
Name
Type
Range
Default
<type>
Discrete
{EXIT|ENTER|TIMe}
ENTER
Explanation
 EXIT: trigger when the input signal exits the specified trigger level range.
 ENTER: trigger when the trigger signal enters the specified trigger level range.
 TIMe: used to specify the hold time of the input signal after it enters the specified
trigger level range. The instrument triggers when the accumulated hold time equals
the windows time.
Return
Format
The query returns EXIT, ENTER, or TIM.
Example
:TRIGger:WINDows:POSition ENTER /*Set the trigger position to enter*/
:TRIGger:WINDows:POSition? /*The query returns ENTER*/
:TRIGger:WINDows:TIMe
Syntax
:TRIGger:WINDows:TIMe <NR3>
:TRIGger:WINDows:TIMe?
Description
Set or query the hold time in windows trigger.
Parameter
Name
Type
Range
Default
<NR3>
Real
8ns to 10s
1μs
Return
Format
The query returns the hold time in scientific notation.
Example
:TRIGger:WINDows:TIMe 0.002 /*Set the hold time to 2ms*/
:TRIGger:WINDows:TIMe? /*The query returns 2.000000e-03*/
Related
Command
:TRIGger:WINDows:POSition

Rigol DS1074Z Plus Specifications

General

Type	Tabletop
Product type	-
Certification	UL 61010-1:2004; CAN/CSA-C22.2 NO. 61010-1-2004; EN 61010-1:2001; IEC 61010-1:2001
Bandwidth	70 MHz
Sampling rate	- MS/s
Channels quantity	4 channels
Minimum time base setting (per division)	5 ns
Power consumption (max)	50 W
Display diagonal	7 \
Non-operating altitude	3000 - 15000 m
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 50 °C

Weight and Dimensions

Depth	122.4 mm
Width	313.1 mm
Height	160.8 mm
