Rigol DS1074Z Plus Programming Guide

Chapter 2 Command System RIGOL
MSO1000Z/DS1000Z Programming Guide 2-195
:TRIGger:DELay:TLOWer
Syntax
:TRIGger:DELay:TLOWer <NR3>
:TRIGger:DELay:TLOWer?
Description
Set or query the lower limit of the delay time in delay trigger. The default unit is s.
Parameter
Name
Type
Range
Default
<NR3>
Real
Related to the delay type
GREater: 8ns to 10s
GOUT or GLESs: 8ns to 9.99s
1μs
Explanation
This command is only available when the delay type (refer to :TRIGger:DELay:TYPe) is
GREater, GOUT, or GLESs.
Return
Format
The query returns the lower limit of the delay time in scientific notation.
Example
:TRIGger:DELay:TLOWer 0.002 /*Set the lower limit of the delay time to 2ms*/
:TRIGger:DELay:TLOWer? /*The query returns 2.000000e-03*/
Related
Command
:TRIGger:DELay:TUPPer

Rigol DS1074Z Plus Specifications

General

Type	Tabletop
Product type	-
Certification	UL 61010-1:2004; CAN/CSA-C22.2 NO. 61010-1-2004; EN 61010-1:2001; IEC 61010-1:2001
Bandwidth	70 MHz
Sampling rate	- MS/s
Channels quantity	4 channels
Minimum time base setting (per division)	5 ns
Power consumption (max)	50 W
Display diagonal	7 \
Non-operating altitude	3000 - 15000 m
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 50 °C

Weight and Dimensions

Depth	122.4 mm
Width	313.1 mm
Height	160.8 mm
