Rigol DS1074Z Plus Programming Guide

RIGOL Chapter 2 Command System
2-60 MSO1000Z/DS1000Z Programming Guide
:DECoder<n>:PARallel:NRTime
Syntax
:DECoder<n>:PARallel:NRTime <time>
:DECoder<n>:PARallel:NRTime?
Description
Set or query the noise rejection time of parallel decoding. The default unit is s.
Parameter
Name
Type
Range
Default
<n>
Discrete
{1|2}
--
<time>
Real
0.00s to 100ms
0.00s
Explanation
Before sending this command, send the :DECoder<n>:PARallel:NREJect command to
turn on the noise rejection function.
Return
Format
The query returns the noise rejection time in scientific notation.
Example
:DECoder1:PARallel:NRTime 0.01 /*Set the noise rejection time to 10ms*/
:DECoder1:PARallel:NRTime? /*The query returns 1.000000e-02*/
:DECoder<n>:PARallel:CCOMpensation
Syntax
:DECoder<n>:PARallel:CCOMpensation <comp>
:DECoder<n>:PARallel:CCOMpensation?
Description
Set or query the clock compensation time of parallel decoding. The default unit is s.
Parameter
Name
Type
Range
Default
<n>
Discrete
{1|2}
--
<comp>
Real
-100ms to 100ms
0.00s
Explanation
 Setting the compensation time can make fine adjustment of the pahse deviation
between the clock line and data line.
 This command is invalid when the CLK channel source is set to OFF
(:DECoder<n>:PARallel:CLK).
Return
Format
The query returns the compensation time in scientific notation.
Example
:DECoder1:PARallel:CCOMpensation 0.01 /*Set the compensation time to 10ms*/
:DECoder1:PARallel:CCOMpensation? /*The query returns 1.000000e-02*/

Rigol DS1074Z Plus Specifications

General

Type	Tabletop
Product type	-
Certification	UL 61010-1:2004; CAN/CSA-C22.2 NO. 61010-1-2004; EN 61010-1:2001; IEC 61010-1:2001
Bandwidth	70 MHz
Sampling rate	- MS/s
Channels quantity	4 channels
Minimum time base setting (per division)	5 ns
Power consumption (max)	50 W
Display diagonal	7 \
Non-operating altitude	3000 - 15000 m
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 50 °C

Weight and Dimensions

Depth	122.4 mm
Width	313.1 mm
Height	160.8 mm
