RIGOL Chapter 2 Command System
2-18 MSO1000Z/DS1000Z Programming Guide
:CURSor:MANual:SOURce
Syntax
:CURSor:MANual:SOURce <source>
:CURSor:MANual:SOURce?
Description
Set or query the channel source of the manual cursor measurement mode.
Parameter
Name
Type
Range
Default
<source>
Discrete
{CHANnel1|CHANnel2|CHANnel3|
CHANnel4|MATH|LA}
CHANnel1
Explanation
 Only the channel that is enabled currently can be selected.
 When LA is selected, the cursor type cannot be set to Y (:CURSor:MANual:TYPE).
Return
Format
The query returns CHAN1, CHAN2, CHAN3, CHAN4, MATH, or LA.
Example
:CURSor:MANual:SOURce CHANnel2 /*Set the channel source to CH2*/
:CURSor:MANual:SOURce? /*The query returns CHAN2*/
:CURSor:MANual:TUNit
Syntax
:CURSor:MANual:TUNit <unit>
:CURSor:MANual:TUNit?
Description
Set or query the horizontal unit in the manual cursor measurement mode.
Parameter
Name
Type
Range
Default
<unit>
Discrete
{S|HZ|DEGRee|PERCent}
S
Explanation
 S: AX, BX, and BX-AX in the measurement results are in "s" and 1/|dX| is in "Hz".
 HZ: AX, BX, and BX-AX in the measurement results are in "Hz" and 1/|dX| is in "s".
 DEGRee: AX, BX, and BX-AX are in "degree".
 PERCent: AX, BX, and BX-AX are expressed in percentage.
Return
Format
The query returns S, HZ, DEGR, or PERC.
Example
:CURSor:MANual:TUNit DEGRee /*Set the horizontal unit to "degree"*/
:CURSor:MANual:TUNit? /*The query returns DEGR*/

Rigol DS1074Z Plus Specifications

General

Type	Tabletop
Product type	-
Certification	UL 61010-1:2004; CAN/CSA-C22.2 NO. 61010-1-2004; EN 61010-1:2001; IEC 61010-1:2001
Bandwidth	70 MHz
Sampling rate	- MS/s
Channels quantity	4 channels
Minimum time base setting (per division)	5 ns
Power consumption (max)	50 W
Display diagonal	7 \
Non-operating altitude	3000 - 15000 m
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 50 °C

Weight and Dimensions

Depth	122.4 mm
Width	313.1 mm
Height	160.8 mm
