30 ProSYS User Guide
Partition Unsetting
Partition unsetting enables you to unset individual partitions within a set
system.
To unset partitions:
1)
Enter your user code and press
.
2)
Select the partition number:
For ProSYS 40 partition 1-4.
For ProSYS 128 partition 1-8.
-OR-
To unset all partitions at once, select 0.
-OR-
For an LCD keypad, scroll with the
or the key to the
required partition (or enter the partition's number).
3)
Press
to confirm. A confirmation message will be
displayed for several seconds.
4)
Repeat the above steps to unset other partitions.
Examples:
Ê To unset partition 3 with code 1234: 1-2-3-4
[3]
Ê To unset ALL partitions: 1-2-3-4
[0]
Ê To unset partitions 3 and 4: 1-2-3-4
[3] [4]
NOTES:
ALL partitions relates to all partitions that are authorized by the security code in
use.
If the Set LED is flashing after unsetting, check the display for activated
(alarmed) zones before proceeding.
