ProSYS User Guide 25
Group Setting
Group setting enables you to set a number of zones within a partition,
using the Function keys. Ask your engineer about defining groups.
To set a group (if the system has one partition):
1)
Enter your code, followed by the Function key
corresponding to the group(s) you want to set. The
selected group is set.
For example, to set Group A, enter: [Code] [A].
NOTE:
If there are faults in the system that need to be confirmed, follow the
same procedure described in step 2 of Full Setting, see page 20.
If Macros are being used, this option is not available.
When the group is set, the Set and Omit LEDs will light
together with a confirmation message that will appear on
the LCD for the time defined by your engineer.
After that time the display will return to the partition status
display and the Power and Ready LEDs light steadily.
2)
To set another group, repeat step 1.
To set a group (if your user code is assigned to more than
one partition):
1)
Enter your user code, then the group letter, then the
partition number, and the group letter again.
For example, to set Group A, enter:
[Code] [A] [Partition No] [A].
2)
To set another group, repeat step 1.
NOTE:
If your system is defined with Quick Setting, press the Function key
corresponding to the group(s) you want to set. The selected group(s) is
set.
