50 ProSYS User Guide
3)
SET CLOCKS:
1) SYSTEM TIME
SET CLOCKS:
1) SYSTEM TIME
Select [5] Scheduler.
4)
SCHEDULER:
SCHEDULER:
01)SCHEDULE 01
01)SCHEDULE 01
SCHEDULER:
SCHEDULER:
01)SCHEDULE 01
01)SCHEDULE 01
Select a program, other than those already
being used for automatic setting or user
limitation.
5)
SCHEDULE 02:
SCHEDULE 02:
1) SET/ UNSET
1) SET/ UNSET
SCHEDULE 02:
SCHEDULE 02:
1) SET/ UNSET
1) SET/ UNSET
Select [2] PO On/Off.
6)
PO ON/OFF S:02
PO ON/OFF S:02
1)
1)
PROG OUTPUTS
PROG OUTPUTS
PO ON/OFF S:02
PO ON/OFF S:02
1)
1)
PROG OUTPUTS
PROG OUTPUTS
Select [1] Programmable Outputs. In this
option, you select the PO that will be
operated in this scheduling program.
7)
PROG OUTPUT S:02
PROG OUTPUT S:02
01)
01)
OUTPUT 01 N
OUTPUT 01 N
PROG OUTPUT S:02
PROG OUTPUT S:02
01)
01)
OUTPUT 01 N
OUTPUT 01 N
Specify whether or not the first PO in the list
should be automatically activated by using
the
key to enter one of the following
characters at the end of the second line in
the LCD:
Y: Automatically activated.
N: Not automatically activated.
8)
Specify whether the three remaining POs in the list should be
automatically activated by selecting them and following step 7
above.
9)
PO ON/OFF S:02
PO ON/OFF S:02
1)
1)
PROG OUTPUTS
PROG OUTPUTS
PO ON/OFF S:02
PO ON/OFF S:02
1)
1)
PROG OUTPUTS
PROG OUTPUTS
Select [2] Date/Time
10)
SELECT A DAY
1) MONDAY
SELECT A DAY
1) MONDAY
Define time windows for the week, as
described in step 12 on page 48.
11)
PO ON/OFF S:02
PO ON/OFF S:02
1)
1)
PROG OUTPUTS
PROG OUTPUTS
PO ON/OFF S:02
PO ON/OFF S:02
1)
1)
PROG OUTPUTS
PROG OUTPUTS
Select [3] HOLIDAY. In this option, you
define the way in which the group of POs is
activated during a holiday period.
