103
Advisory Messages
Requesting Proper Setting
Message Description and Action Reference
An operator card is requested to be inserted into the
Key/card counter (optional).
Insert it.
The Print Cylinder (Drum) is not properly installed.
Slide it into place, holding the handle.
An Ink cartridge is not properly installed.
Insert it into the Ink cartridge holder completely and
lock it.
Master is not properly loaded.
Install a Master roll, if required, and insert the lead
edge into the Master entrance.
Then close the Master making unit.
The Front cover is not properly closed.
Close it tightly, pressing on the lower right-hand
area.
The Scanner table is not properly closed.
Close it tightly, holding it down.
The Master disposal box is not properly loaded.
Insert it completely, holding the handle.
The Master making unit is open.
Open the Scanner table and close the Master
making unit securely.
The Disposal entrance cover is not properly closed.
Close it securely.
p.74
p.96
p.98
p.100
Insert Card in Key/Card Counter
Install Print Cylinder
[Set Print Drum in Place]
Install Ink Cartridge
Master Not Set in Place
Insert Lead Edge of Master into Master
Entrance and Close Master Making Unit
Close Front Cover
Close Scanner Table
Install Master Disposal Box
[Set Master Disposal Box in Place]
Close Master Making Unit
Close Disposal Entrance Cover
Action
Action
Action
Action
Action
Action
Action
Action
Action
102
Advisory Messages
Alphabetical Reference List
A Add Paper .................................................................................................................................................105
B Battery Replacement.................................................................................................................................104
C Check Paper Feed Tray............................................................................................................................107
Close Disposal Entrance Cover ................................................................................................................103
Close Front Cover.....................................................................................................................................103
Close Master Making Unit.........................................................................................................................103
Close Scanner Table ................................................................................................................................103
E Empty Master Disposal Box......................................................................................................................105
I Insert Card in Key/Card Counter...............................................................................................................103
Install Ink Cartridge ...................................................................................................................................103
Install Master Disposal Box.......................................................................................................................103
Install Print Cylinder ..................................................................................................................................103
M Maintenance..............................................................................................................................................105
Master Disposal Error ...............................................................................................................................106
Master Jammed in Disposal Unit ..............................................................................................................106
Master Mis-Feed .......................................................................................................................................105
Master Not Set in Place ............................................................................................................................103
Master was Not Loaded ............................................................................................................................105
N No Ink / Replace Ink Cartridge..................................................................................................................105
No Master on Print Cylinder (Drum) .........................................................................................................106
No Master / Replace Master Roll..............................................................................................................105
O Original Jam ..............................................................................................................................................107
P Paper Jam / Check Paper Ejection Area ..................................................................................................107
Paper Jam / Check Paper Feed Area.......................................................................................................106
Paper Jam / Pull Out Print Cylinder (Drum)..............................................................................................106
Pull Out Print Cylinder (Drum) ..................................................................................................................105
S Set Master Disposal Box in Place.............................................................................................................103
Set Print Drum in Place.............................................................................................................................103
System Error / Press Key ................................................................................................................104
System Error / Rewind Master Roll...........................................................................................................105
System Error / Turn Main Power SW OFF ...............................................................................................104
W Wrong-Type Ink Cartridge.........................................................................................................................104
Wrong-Type Print Cylinder (Drum) ...........................................................................................................104
