ORBIT 16
4) Gradual starter control valve
Closes compressed air supply when power is disconnected.
5) Progressive starter
Allows you to pressurise the machine circuit gradually.
6) Pressure switch
It detects the line pressure when it drops below the set value and puts the machine in emergency
condition.
7) Solenoid valves bank
‒ Solenoid valve
Controls clamp opening and closing.
‒ Solenoid valve
Drives infeed pressure platen lifting and lowering.
‒ Solenoid valve
Drives outfeed pressure platen lifting and lowering.
‒ Solenoid valve
Controls the movement of the coating cutting blade.
‒ Solenoid valve
Controls the ascent/descent of the coating locking pad.
‒ Solenoid valve (Only with 500 reel)
Controls the movement of the gripper.
8) Pressure regulator with pressure gauge
To adjust the pressure of the pressure rollers.
Turn knob to change the pressure values indicated on the pressure gauge.
Important
For further details see the pneumatic diagram.
3.6. ACCESSORIES AVAILABLE UPON REQUEST (OPTIONAL)
‒ carrier unit with rollers or belts lar
er than standard.
‒ Side guides (with rollers) for infeed and outfeed carriers.
‒Drivin
axle.
‒ Idler carriers unit.
On request, we can supply carriers equipped with idle rollers, that can be connected to the motorised
roller conveyors.
The conveyors have a double function: product accumulation and extra support.
‒Sealer.
Its purpose is to lock the tail of the coating against the product.
‒ Pressure rollers of different lengths and material.
‒ MUTING inlet and outlet light curtains for tall products (for the size of the products, see the
diagram in Sect. “Technical data”).
The kit includes a keyboard for machine reset.
3.7. TECHNICAL SPECIFICATIONS
Description Units of
measurement
Value
Coil L = 250 L = 500
Supply voltage 400V 3Ph + N 50/60Hz
Installed power kW 4,7 4,7
Absorption A 17 17
Air consumption Nl/cycle 33 40
Max pressure bar 4/6 4/6
