ORBIT 16
Description
A
verage
level of
p
ressure o
n
the
measurement
surface
(Lpm)
A
coustic power output (LW) Level at the
operator's
place (Lop)
Empty operation 47.0 dB (A) 63.0 dBw (A) 0.00 mW (A) 52.7 dB (A)
Functioning in working
conditions
67.9 dB (A) 83.8 dBw (A) 0.24 mW (A) 75.3 dB (A)
i
Danger - Warning
Prolonged exposure over 80 dB (A) may cause health problems. The use of appropriate protection systems is
recommended (headphones, ear plugs, etc.).
3.10. INSTALLATION ENVIRONMENT CHARACTERISTICS
Careful consideration must be given to the place where the machine is to be installed, in order to ensure that
it may be easily operated, without creating any unnecessary risks for personnel. Therefore we suggest the
following prerequisites:
‒ Room temperature of between +5°C and 40°C.
‒ A suitably aired place so that when the machine is working, the degree of humidity is not unpleasantly
high/low from the point of view of the operator.
‒ A sufficient lighting in order that a pleasant, relaxing working environment is created for the operator.
‒ A boundary area around the immediate working area, for safety reasons, as shown in fig.
‒ A flat surface, steady and without vibrations with adequate weight supporting capacity.
T
he area must be equipped with a power supply socket and a compressed air supply socket.
A
) Operator station (
∗
)
B) Sorrounding area
C) Product outfeed area (
∗
)
d = 1500 mm minimum
x) Compressed air connection point
y) Electric power point
(
∗
) These areas must be suitably sized to
the product being processed.
38/95
