ORBIT 16
3.7.4.MACHINE DIMENSIONS
Orbit 16 B Orbit 16 M
L mm 3698 4396
N mm 2406 2406
H mm 2403 2403
H¹ mm 825 825
W 1110 1110
M 943 943
36/95
