Module Diagnostics and Troubleshooting 5-7
1769-OF2 Specific
Configuration
Error
X400 010 0 0000 0000 General configuration error; no additional information
X401 010 0 0000 0001 invalid output range selected (channel 0)
X402 010 0 0000 0010 invalid output range selected (channel 1)
X403 010 0 0000 0011 invalid output data format selected (channel 0)
X404 010 0 0000 0100 invalid output data format selected (channel 1)
X405 010 0 0000 0101 invalid fault value entered for data format selected (channel 0)
X406 010 0 0000 0110 invalid fault value entered for data format selected (channel 1)
X407 010 0 0000 0111 invalid program value entered for data format selected (channel 0)
X408 010 0 0000 1000 invalid program value entered for data format selected (channel 1)
(1)
X represents the “Don’t Care” digit.
Table 5.4 1769-IF4 and -OF2 Extended Error Codes
Error Type Hex
Equivalent
(1)
Module
Error
Code
Extended Error
Information
Code
Error Description
Binary Binary
Table 5.5 1769-IF8 Extended Error Codes
Error Type Hex
Equivalent
(1)
Module
Error
Code
Extended Error
Information
Code
Error Description
Binary Binary
No Error X000 000 0 0000 0000 No Error
General Common
Hardware Error
X200 001 0 0000 0000 General hardware error; no additional information
X201 001 0 0000 0001 Power-up reset state
Hardware-
Specific Error
X300 001 0 1000 0000 General hardware error, loss of external 24V dc power
X301 001 0 1000 0001 Microprocessor hardware error
X302 001 1 0000 0010 A/D converter communication error
