Publication 1769-UM002B-EN-P - July 2005
5-8 Module Diagnostics and Troubleshooting
1769-IF8 Specific
Configuration
Error
X400 010 0 0000 0000 General configuration error; no additional information
X401 010 0 0000 0001 invalid input range selected (channel 0)
X402 010 0 0000 0010 invalid input range selected (channel 1)
X403 010 0 0000 0011 invalid input range selected (channel 2)
X404 010 0 0000 0100 invalid input range selected (channel 3)
X405 010 0 0000 0101 invalid input range selected (channel 4)
X406 010 0 0000 0110 invalid input range selected (channel 5)
X407 010 0 0000 0111 invalid input range selected (channel 6)
X408 010 0 0000 1000 invalid input range selected (channel 7)
X409 010 0 0000 1001 invalid input filter selected (channel 0)
X40A 010 0 0000 1010 invalid input filter selected (channel 1)
X40B 010 0 0000 1011 invalid input filter selected (channel 2)
X40C 010 0 0000 1100 invalid input filter selected (channel 3)
X40D 010 0 0000 1101 invalid input filter selected (channel 4)
X40E 010 0 0000 1110 invalid input filter selected (channel 5)
X40F 010 0 0000 1111 invalid input filter selected (channel 6)
X410 010 0 0001 0000 invalid input filter selected (channel 7)
X411 010 0 0001 0001 invalid input format selected (channel 0)
X412 010 0 0001 0010 invalid input format selected (channel 1)
X413 010 0 0001 0011 invalid input format selected (channel 2)
X414 010 0 0001 0100 invalid input format selected (channel 3)
X415 010 0 0001 0101 invalid input format selected (channel 4)
X416 010 0 0001 0110 invalid input format selected (channel 5)
X417 010 0 0001 0111 invalid input format selected (channel 6)
X418 010 0 0001 1000 invalid input format selected (channel 7)
X419 010 0 0001 1001 alarm not enabled (channel 0)
X41A 010 0 0001 1010 alarm not enabled (channel 1)
Table 5.5 1769-IF8 Extended Error Codes
Error Type Hex
Equivalent
(1)
Module
Error
Code
Extended Error
Information
Code
Error Description
Binary Binary
To Next Page
