Publication 1769-UM002B-EN-P - July 2005
Module Diagnostics and Troubleshooting 5-9
1769-IF8 Specific
Configuration
Error
X41B 010 0 0001 1011 alarm not enabled (channel 2)
X41C 010 0 0001 1100 alarm not enabled (channel 3)
X41D 010 0 0001 1101 alarm not enabled (channel 4)
X41E 010 0 0001 1110 alarm not enabled (channel 5)
X41F 010 0 0001 1111 alarm not enabled (channel 6)
X420 010 0 0010 0000 alarm not enabled (channel 7)
X421 010 0 0010 0001 invalid alarm data selected (channel 0)
X422 010 0 0010 0010 invalid alarm data selected (channel 1)
X423 010 0 0010 0011 invalid alarm data selected (channel 2)
X424 010 0 0010 0100 invalid alarm data selected (channel 3)
X425 010 0 0010 0101 invalid alarm data selected (channel 4)
X426 010 0 0010 0110 invalid alarm data selected (channel 5)
X427 010 0 0010 0111 invalid alarm data selected (channel 6)
X428 010 0 0010 1000 invalid alarm data selected (channel 7)
X429 010 0 0010 1001 invalid real time sample rate value
(1)
X represents the “Don’t Care” digit.
Table 5.5 1769-IF8 Extended Error Codes
Error Type Hex
Equivalent
(1)
Module
Error
Code
Extended Error
Information
Code
Error Description
Binary Binary
