108 Rockwell Automation Publication 20P-TG002B-EN-P - February 2018
Appendix A Schematics
Figure 16 - Field Board and SCR/Dual Diode Module Connections Diagram
X2
V1 U1
X2
B
UF
VF
VF1
UF1
UF VF
2U1
2V1
2C1
2D1
XP-2
XP-1
XP-8
XP-7
D1 C1
X2 X2
A
1U1
1V1
X3-1
X3-2
XFCD-3
XFCD-2
XFCD-4
XFCD-1
N
M
P
To Pulse
Transformer
Board X3
Connector
To Motor Field Connections
From Incoming AC Line
TA1
470k 470k 470k 470k
470k 470k 470k 470k
