40 Rockwell Automation Publication 20P-TG002B-EN-P - February 2018
Chapter 3 Part Replacement Procedures
Replacement Parts Kits
Table 1 2 lists the spare parts kits available for PowerFlex DC frame B drives.
Table 12 - Spare Part Kits
Description Kit Cat. No. Instructions
Page
Fuses/Fuse Holders
Switching Power Supply Board (Revision H and Lower only) Fuse -
Ferrule 5 x 20 mm, 3.15 A 250V (SW2-32)
(1)
SK-20P-S7169 60
Switching Power Supply Board Fuse - Ferrule 5 x 20 mm, 2.5 A 250V
(SW2-32)
(2)
SK-20P-S8B29
Switching Power Supply Board Fuse Holder SK-20P-S7G84 60
Pulse Transformer Board (FIR1) Fuses (Qty 3) - Ferrule 6 x 32 mm, 16 A
500V
SK-20P-S824B 62
Field Circuit Fuses (Qty 2) - Ferrule 10 x 38 mm, 25 A 600V SK-20P-S823B 74
Field Circuit Fuse Holder SK-20P-S8N29 74
Accessories
DPI / HIM Assembly SK-DC1-CVR1-A1 42
Control Circuit Boards
Resolver Feedback and Interface Boards 20P-RES-A0 48
I/O Expansion Board (TBO-32) 20P-S5V62 52
115V AC to 24V DC I/O Converter Board 20P-S520L 54
Control Circuit Board SK-20P-S5RP1 55
Power Circuit Boards
Pulse Transformer Board for 230V AC Regen. Drives, 146…434 A
(FIR2-41)
SK-20P-S5N08 62
Pulse Transformer Board for 460/480V AC Regen. Drives, 167…412 A
(FIR2-51)
SK-20P-S5N18
Pulse Transformer Board for 575V AC Regen. Drives, 67…405 A (FIR2-
61)
SK-20P-S5N421
Switching Power Supply Board (SW2-32) SK-20P-S5N10 62
Field Board (PFC2A-31) SK-20P-S5N25 75
AC Line Snubber Board for 230V AC Regen. Drive (SN4-31) SK-20P-S5N13 78
AC Line Snubber Board for 460/480V AC Regen. Drive (SN5-31) SK-20P-S5N14
AC Line Snubber Board 0.22 μF for 575V AC Regen. Drive (SN7-32) SK-20P-S5N425
AC Line Snubber Board 0.33 μF for 575V AC Regen. Drive (SN7-32) SK-20P-S5N428
Power Components
AC Current Transducers (Qty 2), 600 A / 0.2 A SK-20P-S777H 90
Field Dual Diode Module, 1K6V, 40 A SK-20P-S799F 77
Field SCR Module, 1K6V, 25 A SK-20P-S7F73
Bimetal Thermostat, 80 °C ± 3 (Qty 2),
230V Regen. Drives, 360 and 434 A,
460/480V Regen. Drives, 330 and 412, or
575V Regen. Drive, 405 A
SK-20P-S7G29 94
Bimetal Thermostat, 85 °C ±3 (Qty 2),
230V Regen. Drives, 146…265 A,
460/480V Regen. Drives, 167…250 A, or
575V Regen. Drives, 67…270 A
SK-20P-S7G33
