Rockwell Automation Publication 20P-TG002B-EN-P - February 2018 41
Part Replacement Procedures Chapter 3
SCR Modules (Qty 6) 1K2V 130 A, 230V AC Regen. Drives, 146 and
180 A
SK-20P-S7F48 80
SCR Modules (Qty 6) 1K2V 160 A, 230V AC Regen. Drive, 218 A SK-20P-S7F49
SCR Modules (Qty 6) 1K2V 210 A, 230V AC Regen. Drive, 265 A SK-20P-S7F42
SCR Modules (Qty 6) 1K2V 320 A, 230V AC Regen. Drives, 360 and
434 A
SK-20P-S727F
SCR Modules (Qty 6) 1K6V 210 A, 460/480V AC Regen. Drive, 250 A SK-20P-S7F41
SCR Modules (Qty 3) 1K6V 210 A, 460/480V AC Non-Regen. Drive,
250 A
SCR Modules (Qty 6) 1K6V 160 A, 460/480V AC Regen. Drive, 207 A SK-20P-S7F79
SCR Modules (Qty 3) 1K6V 160 A, 460/480V AC Non-Regen. Drive,
207 A
SCR Modules (Qty 6) 1K2V 130 A, 460/480V AC Regen. Drive, 167A SK-20P-S7F78
SCR Modules (Qty 3) 1K2V 130 A, 460/480V AC Non-Regen. Drive,
167A
SCR Modules (Qty 6) 1K6V 320 A, 460/480V AC Regen. Drives, 330 and
412 A
SK-20P-S737F
SCR Modules (Qty 3) 1K6V 320 A, 460/480V AC Non-Regen. Drives,
330 and 412 A
SCR Modules (Qty 6) 1K8V 130 A, 575V AC Regen. Drives, 67…135 A SK-20P-S79F7
SCR Modules (Qty 3) 1K8V 130 A, 575V AC Non-Regen. Drives,
67…135 A
SCR Modules (Qty 6) 1K8V 250 A, 575V AC Regen. Drive, 270 A SK-20P-S8HI6
SCR Modules (Qty 3) 1K8V 250 A, 575V AC Non-Regen. Drive, 270 A
SCR Modules (Qty 6) 1K8V 320 A, 575V AC Regen. Drive, 405 A SK-20P-S79F9
SCR Modules (Qty 3) 1K8V 320 A, 575V AC Non-Regen. Drive, 405 A
Ventilation Components
Cooling Fans, (Qty 2) 24V DC, 100 CFM,
230V AC Drives, 146…265 A,
460/480V AC Drives, 167…250 A, or
575V AC Drives, 67…270 A
SK-20P-S7G71 99
Cooling Fans, (Qty 2) 150 x 55 mm, 24V DC, 212 CFM,
230V AC Drives, 360 and 434 A
460/480V AC Drives, 320 and 412 A
575V AC Drives, 405 A
SK-20P-S7G78
(1) This kit contains one fuse only. Order 1 kit for switching power supply circuit boards, revision “H” and lower.
(2) This kit contains one fuse only. Order 1 kit for switching power supply circuit boards, revision “H” and lower. Order 2 kits for
switching power supply circuit boards, revision “I” and higher.
Table 12 - Spare Part Kits (Continued)
Description Kit Cat. No. Instructions
Page
