12 Rockwell Automation Publication 20P-TG002B-EN-P - February 2018
Chapter 1 Before You Begin Testing, Maintenance or Repairs
Commonly Used Tools
Service Tools
This list of basic service tools which will cover needs of tools for repair and
maintenance measurements.
Software Tools
You can use Connected Components Workbench® software or DriveExecutive™
software to monitor, upload, or download system parameters. You can also
view current alarm and fault information.
Item Details
Digital multimeter Digital multimeter, capable of AC and DC voltage, continuity, resistance, and
forward diode bias tests. Fluke model 87 III or equivalent (recommended).
Oscilloscope Portable, digitizing, dual channel scope, with isolation
Current clamp 3x drive rated armature current output
Soldering station Soldering / de soldering
Torque wrench 1…12 N•m
Torque wrench 6…50 N•m
Box wrench 7 mm, 8 mm, 10 mm, 13 mm, 17 mm, 19 mm, 22 mm
Socket extension 230 mm
Wrench 7 mm, 8 mm, 10 mm, 13 mm, 17 mm, 19 mm, 22 mm
Wire cutter
Nose pliers
Crimping tools For cable terminals 1.5…240
Angle wrench
Screw drivers:
Flat nose 7 x 2 mm
Hexalobular T15, T20, T25
Phillips #1, 2, 3
Hexagonal wrench #4, 5, 6
ESD-protected place of work Working surface, floor covering, seat and ground connections
ESD-protective clothing Wrist wrap, shoes, overall clothing (coat)
