9. Record all switch and jumper settings on the control board. See the
PowerFlex DC Digital Drive User Manual, publication 20P-UM001
,
for more information.
Jumper
/Switch
Function Setting
S4 Configures the input voltage of the DC analog tachometer.
S9 Configures the input signal of analog input 1 (terminals 1 and 2):
Par 71 [Anlg In1 Config] must be programmed to match the input signal type
selected with this switch.
S10 Configures the input signal of analog input 2 (terminal 3 and 4):
Par 76 [Anlg In2 Config] must be programmed to match the input signal type
selected with this switch.
S11 Configures the input signal of analog input 3 (terminals 5 and 6):
Par 81 [Anlg In3 Config] must be programmed to match the input signal type
selected with this switch.
S14 Field current resistors settings.
The value that is selected with switch S14 must be entered in Par 374 [Drv Fld
Brdg Cur] when the drive is commissioned.
S14-1 =
S14-2 =
S14-3 =
S14-4 =
S14-5 =
S14-6 =
S14-7 = (not used)
S14-8 = (not used)
S15 Configures the control circuit board to the appropriate drive size. S15-1 =
S15-2 =
S15-3 =
S15-4 =
S15-5 =
S15-6 =
S15-7 =
S15-8 =
S20 Monitoring (reported by Par 652 [Encoder Err Chk]) of the Z channel of the
Digital Encoder on connector XE2.
Off Position Z-channel monitored
On Position Z-channel not monitored
S21 Encoder power supply voltage and input adaptation selection:
This switch setting determines both the power supply (input) and feedback
level (output) voltage of the connected encoder.
Note: When control power is supplied to the drive, the appropriate light-
emitting diode lights to indicate the selection of the switch.
ENC_5 +5V encoder (+2.5…5.4V input range)
ENC_12 +12…15V encoder (+5.4V…15.2V input range)
IMPORTANT Mark all connections and wires before removal to avoid incorrect
wiring during reassembly.
