Bulletin 284G CIP Information C-17
Instances 8…11 are ZIP Consumers. The following instance
attributes will be supported:
Table C.39 Connection Object instance 8...11 Attributes
The following services are implemented for the Connection Object
Table C.40 Connection Objects Common Services:
Attribute
ID
Access
Rule
Name
Data
Type
Value
1 Get
State
USINT
0=nonexistant
1=configuring
3=established
2 Get Instance Type USINT 1=I/O Connection
3 Get
Transport Class Trigger
USINT
0x20 (COS,
unacknowledged)
4 Get Produced Connection ID UINT FFFF (not producing data)
5 Get
Consumed Connection ID
UINT
01101xxxxxx
xxxxxx=node address
6 Get Initial Comm Characteristics USINT 0xF0 (unacknowledged)
7 Get Produced Connection Size UINT 0
8 Get Consumed Connection Size UINT 8
9 Get/Set Expected Packet Rate UINT in milliseconds
12 Get Watchdog Action USINT 2=auto reset
13 Get
Produced Connection Path
Length
UINT
0
14 Get Produced Connection Path 0
15 Get
Consumed Connection Path
Length
UINT
8
16 Get Consumed Connection Path 21 0E 03 25 01 00 30 02
Service
Code
Implemented for
Service
Name
Class Instance
0x05 No Yes Reset
0x0E No Yes Get_Attribute_Single
0x10 No Yes Set_Attribute_Single
