C-16 Bulletin 284G CIP Information
Instances 5…7 will be available Group 3 explicit message
connections that are allocated through the UCMM. The following
attributes are supported
Table C.38 Connection Object Instance 5...7 Attributes:
Attribute
ID
Access
Rule
Name
Data
Type
Value
1 Get
State
USINT
0 = non-existent
1 = configuring
3 = established
4 = timed out
2 Get
Instance Type
USINT
0 = Explicit
Message
3 Get
Transport Class Trigger
USINT
0x83 — Server,
Transport Class 3
4 Get
Produced Connection ID
UINT
Depends on message
group and Message ID
5 Get
Consumed Connection ID
UINT
Depends on message
group and Message ID
6 Get Initial Comm Characteristics USINT 0x33 (Group 3)
7 Get Produced Connection Size UINT 0
8 Get Consumed Connection Size UINT
9 Get/Set Expected Packet Rate UINT in milliseconds
12 Get
Watchdog Action
USINT
01 = auto delete
03 = deferred delete
13 Get
Produced Connection Path
Length
UINT
0
14 Get Produced Connection Path Empty
15 Get
Consumed Connection Path
Length
UINT
0
16 Get Consumed Connection Path Empty
