Bulletin 284G CIP Information C-21
The following State Transition Diagram is used for Unbound DOP
Instances 3…8 when they are not used in a Devicelogix™ Program
Figure C.1 State Transition Diagram — Unbound DOP 3…8
Non-Existant
Available
Idle
Ready
Run
DNet Fault
Protection Fault
Receive Idle
Protection Fault
DNet Fault
DNet Fault
DNet
Fault
Protection Fault
DNet
Idle
Receive
Data
Connection Transitions to Established
Power On
Connection Transitions to Established
Protection Fault
Protection Fault Reset
