2-10 Installation and Wiring
Figure 2.7 Bulletin 284G ArmorStart
LED Status
Indication
Motor
Connector
Dynamic
Brake Connector
Control Brake
Connector
Ground
Te rm ina l
3-Phase
Receptacle
Control Power
Receptacle
DeviceNet
Connection
(Mini/M18)
Local Disconnect
6 Inputs
(Micro/M12)
