Renewal Parts G-7
Figure G.7 Bulletin 284G Safety Control Module Renewal Part Catalog
Structure
Table G.9 Bulletin 284G Control Module with Sensorless Vector Control ,
IP67/NEMA 4, Up to 600V
Bulletin
Number
Communications
D DeviceNet™
Enclosure Type
F Type 4 (IP67)
284
D – F V D2P3 S – N – RG – Option 1 – Option 2 – Option 3
Torque Performance Mode
V Sensorless Vector
Control Volts per Hz
Option 3
EMI EMI Filter
Option 2
CB Control Brake Connector
DB1 DB Brake Connector for IP67
Dynamic Brake Resistor
Option 1
Blank Status Only
Motor Media Type
RG Round
Control Module
N Control Module Only
Control Voltage
S 24V DC
Code
Output
Current
[A]
kW Hp
480V Drive
D1P4 1.4 0.4 0.5
D2P3 2.3 0.75 1
D4P0 4 1.5 2
D6P0 6 2.2 3
D7P0 7.6 4 5
Output Current
Input Voltage kW Hp
Output
Current
Cat. No.
120 V AC
Control Voltage
380…480V
50/60 Hz
3-Phase
0.4 0.5 1.4 A
284G-FVD1P4S-N-RG-CB-DB1-EMI
0.75 1.0 2.3 A
284G-FVD2P3S-N-RG-CB-DB1-EMI
1.5 2.0 4.0 A
284G-FVD4P0S-N-RG-CB-DB1-EMI
2.2 3.0 6.0 A
284G-FVD6P0S-N-RG-CB-DB1-EMI
3.0 5.0 7.6 A
284G-FVD7P6S-N-RG-CB-DB1-EMI
