I-6 Step Logic, Basic Logic and Timer/Counter Functions
9 Step if Logic In1 is active (logically true) and Logic In2 is not active (logically false). XOR
A Step if Logic In2 is active (logically true) and Logic In1 is not active (logically false). XOR
b Step after (Stp Logic Time x) and Logic In1 is active (logically true). TIMED AND
C Step after (Stp Logic Time x) and Logic In2 is active (logically true). TIMED AND
d Step after (Stp Logic Time x) and Logic In1 is not active (logically false). TIMED OR
E Step after (Stp Logic Time x) and Logic In2 is not active (logically false). TIMED OR
F Do not step OR no jump to, so use Digit 0 logic. IGNORE
Setting Description Logic
0 Skip Step (jump immediately). SKIP
1 Step based on the time programmed in the respective (Stp Logic Time x) parameter. TIMED
2 Step if Logic In1 is active (logically true). TRUE
3 Step if Logic In2 is active (logically true). TRUE
4 Step if Logic In1 is not active (logically false). FALSE
5 Step if Logic In2 is not active (logically false). FALSE
6 Step if either Logic In1 or Logic In2 is active (logically true). OR
7 Step if both Logic In1 and Logic In2 is active (logically true). AND
8 Step if neither Logic In1 or Logic In2 is active (logically true). NOR
9 Step if Logic In1 is active (logically true) and Logic In2 is not active (logically false). XOR
A Step if Logic In2 is active (logically true) and Logic In1 is not active (logically false). XOR
b Step after (Stp Logic Time x) and Logic In1 is active (logically true). TIMED AND
C Step after (Stp Logic Time x) and Logic In2 is active (logically true). TIMED AND
d Step after (Stp Logic Time x) and Logic In1 is not active (logically false). TIMED OR
E Step after (Stp Logic Time x) and Logic In2 is not active (logically false). TIMED OR
F Use logic programmed in Digit 1. IGNORE
Setting Description Logic
