3-6 Bulletin 280G/281G Programmable Parameters
Bit
Function:
1514131211109876543210
——————————————— X Explicit Connection
—————————————— X — I/O Connection
————————————— X —— Explicit Fault
———————————— X ——— I/O Fault
——————————— X ———— I/O Idle
———————— X X X ————— Reserved
——————— X ———————— ZIP 1 Cnxn
—————— X ————————— ZIP 1 Flt
————— X —————————— ZIP 2 Cnxn
———— X ——————————— ZIP 2 Flt
——— X ———————————— ZIP 3 Cnxn
—— X ————————————— ZIP 3 Flt
— X —————————————— ZIP 4 Cnxn
X ——————————————— ZIP 4 Flt
Starter Command
The parameter provides the
status of the starter command.
Parameter Number 7
Access Rule GET
Data Type WORD
Group DeviceLogix
Units —
Minimum Value 0
Maximum Value 255
Default Value 0
Bit
Function:
76543210
——————— X Run Fwd
—————— X — Run Rev
————— X —— Fault Reset
———— X ——— Reserved
——— X ———— Reserved
—— X ————— Reserved
— X —————— Reserved
X ——————— Reserved
Network Override
This parameter allows for the
local logic to override a Network
fault
0 = Disable
1 = Enable
Parameter Number 8
Access Rule GET/SET
Data Type BOOL
Group DeviceLogix
Units —
Minimum Value 0
Maximum Value 1
Default Value 0
