Bulletin 280G/281G Programmable Parameters 3-15
Set to Defaults
This parameter if set to 1 will set
the device to the factory defaults
0=No Operation
1=Set to Defaults
Parameter Number 47
Access Rule GET/SET
Data Type BOOL
Group Misc.
Units —
Minimum Value 0
Maximum Value 1
Default Value 0
Base Enclosure
Indicates the ArmorStart Base
unit enclosure rating
Bit 0 = IP67
Bit 1 = Nema 4X
Bit 2 = SIL3/CAT4
Bit 3-15 = Reserved
Parameter Number 56
Access Rule GET
Data Type WORD
Group Misc.
Units —
MinimumValue 0
Maximum Value 65535
Default Value 0
Base Options
Indicates the options for the
ArmorStart Base unit
Bit 0 = Reserved
Bit 1 = Reserved
Bit 2 = CP Fuse Detect
Bits 3-7 = Reserved
Bit 8 = 10A Base
Bit 9 = 25A Base
Bit 10-15 = Reserved
Parameter Number 57
Access Rule GET
Data Type WORD
Group Misc.
Units —
MinimumValue 0
Maximum Value 65535
Default Value 0
Wiring Options
Bit 0 = Conduit
Bit 1 = Round Media
Bits 2-15 = 28xG
Bits 3-15 = Reserved
Parameter Number 58
Access Rule GET
Data Type WORD
Group Misc.
Units —
MinimumValue 0
Maximum Value 65535
Default Value 0
Starter Enclosure
Bit 0 = IP67
Bit 1 = NEMA 4x
Bit 2 = SIL3/CAT4
Bits 3-15 reserved
Parameter Number 59
Access Rule GET
Data Type WORD
Group Misc.
Units —
MinimumValue 0
Maximum Value 65535
Default Value —
