Bulletin 280G/281G Programmable Parameters 3-19
Zone #4 Mask
Bit enumerated consumed data
mask for zone 4. Each bit
represents a byte in consumed
data up to 8 bytes in length. If a
mask bit is set, the
corresponding consumed data
byte is placed in the DeviceLogix
data table
Parameter Number 81
Access Rule GET/SET
Data Type BYTE
Group ZIP Parameters
Units —
MinimumValue 0
Maximum Value 255
Default Value 0
Zone #1 Offset
The byte offset into the ZIP data
portion of the DeviceLogix data
table to place the chosen
consumed data bytes for zone 1.
Parameter Number 82
Access Rule GET/SET
Data Type UINT
Group ZIP Parameters
Units —
MinimumValue 0
Maximum Value 7
Default Value 0
Zone #2 Offset
The byte offset into the ZIP data
portion of the DeviceLogix data
table to place the chosen
consumed data bytes for zone 2.
Parameter Number 83
Access Rule GET/SET
Data Type UNIT
Group ZIP Parameters
Units —
MinimumValue 0
Maximum Value 7
Default Value 0
Zone #3 Offset
The byte offset into the ZIP data
portion of the DeviceLogix data
table to place the chosen
consumed data bytes for zone 3.
Parameter Number 84
Access Rule GET/SET
Data Type UNIT
Group ZIP Parameters
Units —
MinimumValue 0
Maximum Value 1
Default Value 0
Zone #4 Offset
The byte offset into the ZIP data
portion of the DeviceLogix data
table to place the chosen
consumed data bytes for zone 4.
Parameter Number 85
Access Rule GET/SET
Data Type UNIT
Group ZIP Parameters
Units —
MinimumValue 0
Maximum Value 1
Default Value 0
