5. Follow the on-screen instructions and enter the corrected values for [New Scanning Value] and [New

Feeding Value].

6. Click [Apply].

The values in [New Scanning Value] and [New Feeding Value] change to "0."

7. Click [Close].

Cutting / Printing and Cutting

44 Optimizing the Output Quality
