Printing with Crop Marks Followed by Cutting
With this machine, you can print with crop marks, and then reload this media and cut it.
(Example: Perform lamination or other processing after printing, then reload the media and perform cut-
ting.)
In this situation, carry out alignment to prevent misalignment of the printing results and the cutting lines.
Refer to [Performing cutting]>[Print laminate and cut] in the [VersaWorks Help] and perform the follow-
ing procedure.
Procedure
1. Print with crop marks.
2. Print with crop marks, remove the media, and then reload it.
Points for Media Setting
Place the crop marks ( ) on the blade protector ( ).
Ensure that the angle is less than 5 degrees. Failing to do so will make alignment impossible.
3. Align to the printed crop marks and perform cutting.
P. 33Step 5: Starting Print Output
