4. Follow the on-screen instructions and enter the values for [New Scanning Value] and [New Feeding Val-

ue].

5. Click [Apply].

The values in [New Scanning Value] and [New Feeding Value] change to "0."

6. Click [Close].

Performing Printing and Cutting Separately

48 Optimizing the Output Quality
