41
Reference Manual
00809-0100-4803, Rev GA
Configuration
September 2017
Configuration
Mass/volume conversion example
To find the Base per Custom relationship for a custom unit of kilograms per hour (kg/h) and a base unit of
grams per hour (g/h), input the following:
Custom Unit = kg/h
Base Unit = g/h
Because:
1 kg (Kilogram) = 1000 g (Grams)
Then:
1 kg/h = ⫻ = 1000 g/h
1 kg/h = 1000 g/h
Therefore:
Base per Custom = = = 1000
Figure 2-28. Flow Rate Custom Units - Mass/Volume Conversion Example
1kg⋅
1h⋅
--------------
1000 g⋅
1kg⋅
---------------------
Number of Base Units
1xCustomxUnit
----------------------------------------------------------------------
1000 g h⁄⋅
1kgh⁄⋅
----------------------------
