Section
2-1
2 Installation
INTRODUCTION
This section covers the installation procedures for the
Model 8712C/U/H Magnetic Flowmeter Transmitter. See the flowtube
manual (document number 00809-0100-4727) for specific flowtube
installation procedures.
SAFETY MESSAGES
This symbol is used throughout this manual to indicate that special
attention to warning information is required.
Instructions and procedures in this section may require special
precautions to ensure the safety of the personnel performing the
operations. Please refer to the following safety messages before
performing any operation in this section.
TRANSMITTER SYMBOLS
Caution symbol — check product documentation for details
Protective conductor (grounding) terminal
Failure to follow these installation guidelines could result in death or serious injury:
Installation and servicing instructions are for use by qualified personnel only. Failure to
follow safe installation guidelines or performing any servicing other than that contained
in this manual may result in death or serious injury. Do not perform any servicing other
than that contained in the operating instructions, unless qualified.
Explosions can cause death or serious injury. Verify that the operating
environment of the flowtube and transmitter is consistent with the appropriate FM
or CSA approval.
Do not connect a Model 8712C/U/H to a non-Rosemount flowtube that is located in
an explosive atmosphere.
Failure to comply could result in an electrical spark or an explosion.
