Model 8712C/U/H Magnetic Flowemter Transmitters
6-6
ORDERING INFORMATION
NC = No Charge
NA = Not Applicable
Availability
Model Product Description C U H
8712C Magnetic Flowmeter Transmitter •NANA
8712U Universal Magnetic Flowmeter Transmitter NA • NA
8712H High-Signal Magnetic Flowmeter Transmitter (For use with Model 8707 High-Signal Flowtube only.) NA NA •
Code Transmitter Style C U H
R Remote (2-inch pipe or surface mounting) • • •
T Integral (mounted to flowtube) •••
Code Power Supply Voltage C U H
03 10–30 V dc ••NA
12 115 V ac, 50–60 Hz •••
24 230 V ac, 50–60 Hz ••NA
Code Hazardous Location Certifications C U H
N0
Factory Mutual (FM) Class I, Division 2 Approval for nonflammable fluids;
Canadian Standards Association (CSA) Class I, Division 2 Approval • • •
N5 Factory Mutual (FM) Class I, Division 2 Approval for flammable fluids • • •
CE CE Marking ••NA
Code Options C U H
B6 Stainless Steel 4-bolt Kit for 2-inch Pipe Mount • • •
C1 Custom Configuration (Completed CDS 00806-0100-4668 required with order) • • •
C4 Analog output levels compliant with NAMUR recommendations NE43, 18-January-1994
(1)
and high alarm level •••
CN Analog output levels compliant with NAMUR recommendations NE43, 18-January-1994
(1)
and low alarm level •••
D1 High Accuracy Calibration [0.25% of rate from 3 to 30 ft/s (0.9 to 10 m/s)] matched flowtube
and transmitter system
(2)
•NANA
M4 Local Operator Interface (LOI) •••
T1 Battery-backed Totalizer ••NA
Typical Model Number: 8712C R 12 N 0 M 4
(1) NAUMUR-compliant operation; alarm latch operations are pre-set at the factory and can not be changed to standard operation in the field.
(2) Option Code must be ordered for both flowtube and transmitter.
