Model 8712C/U/H Magnetic Flowmeter Transmitters
5-10
Install the LOI
Electronics Assembly
Complete the following steps to install a new LOI electronics assembly.
1. Disconnect power from the transmitter.
2. Connect the LOI keypad connector to the LOI electronics
assembly and snap it into place.
3. Connect the LOI connector to the LOI electronics and
snap it into place.
4. Position the LOI electronics assembly so that the LOI display is
shown clearly through the LOI window in the housing cover.
5. Tighten the six LOI holding screws until they are snug.
6. Close the transmitter housing cover and tighten the cover screw.
RETURN OF MATERIALS
To expedite the return process outside the United States, contact the
nearest Fisher-Rosemount representative.
The North American Response Center (1-800-654-7768) will assist you
with any needed information or materials and is available for users
within the United States and Canada, 24 hours a day.
The center will ask for product model and serial numbers, and will
provide a Return Material Authorization (RMA) number. The center
will also ask for the name of the process material the product was last
exposed to. Mishandling products exposed to a hazardous substance
may result in death or serious injury. A copy of the Material Safety
Data Sheet may be required, depending on the nature of the hazardous
substance as defined by OSHA.
The North American Response Center will provide the additional
information and procedures necessary to return goods exposed to
hazardous substances.
See Safety Messages on page 5-1 for complete warning information.
