Rosemount 8712C - Standard Configuration

Model 8712C/U/H Magnetic Flowemter Transmitters
6-8
STANDARD
CONFIGURATION
CUSTOM
CONFIGURATION
(OPTION CODE C1)
If Option Code C1 is ordered, Configuration Data Sheet (CDS)
00806-0100-4668 must be submitted at the time of order.
➆
LOI Connector Assembly 08712-0016-0004
➇
Switch Assembly Cover 08712-0017-0001
➈
Housing Base Assembly with Terminal Block Assembly 08712-0053-0001
– Upper Assembly Cover without LOI 08712-0058-0001
Transmitter and Flowtube Accessories
– U-bolt for 2-inch Pipe Mount Kit (includes 1 each) C098300002
–
Multi-Point Reference Calibration Standard
(for use with Model 8712C, Model 8712U, or Model 8732C Transmitters) 8714DQ4
– Flowtrol Totalizer (Kessler-Ellis) 08712-0400-0002
– Spare Model 8714D Cable (for Model 8712C or 8712U transmitters) 08714-0205-0001
– SST U-bolt for 2-inch Pipe Mount Kit C09830006
Contact factory for Model 8712H spare parts.
Drawing Reference Part Description Part Number
Engineering Units: ft/sec
4 mA (1 V dc): 0
20 mA (5 V dc): 30
Tube Size: 3-inch
Flowtube
Calibration Number: 1000005010000000.
