Rosemount 8712C - Fischer and Porter Flowtubes; Model 10 D1418 Flowtube to Model 8712 U Transmitter

Model 8712C/U/H Magnetic Flowmeter Transmitters
B-10
FISCHER AND PORTER
FLOWTUBES
Connect coil drive and electrode cables as shown in Figure B-9.
Model 10D1418 Flowtube to
Model 8712U Transmitter
FIGURE B-9. Wiring Diagram for
Fischer and Porter Flowtube Model
10D1418 and Rosemount
Model 8712U
ROSEMOUNT MODEL
8712U TRANSMITTER
Electrode Connections
U1
U2
G
8
6
7
L1
L2
5
3
2
1
Coil Connections
8712-1000A01B
This is a pulsed dc
magnetic flowmeter. Do
not connect ac power
to the flowtube or to
terminals 1 and 2 of
the transmitter,or
replacement of the
electronics board will
be necessary.
TABLE B-9. Fischer and Porter Model
10D1418 Flowtube Wiring Connections
Rosemount
Model 8712U
Fischer and Porter
Model 10D1418
Flowtubes
1L1
2L2
Chassis Ground
17 3
18 1
19 2
