Rosemount 8712C - Model 10 D1465 and Model 10 D1475 Flowtubes (Integral) to Model 8712 U Transmitter

Model 8712C/U/H Magnetic Flowmeter Transmitters
B-14
Model 10D1465 and
Model 10D1475 Flowtubes
(Integral) to Model 8712U
Transmitter
Connect coil drive and electrode cables as shown in Figure B-13.
FIGURE B-13. Wiring Diagram for
Fischer and Porter Flowtube Model
10D1465 and Model 10D1475
(Integral) and Rosemount
Model 8712U
8712-1000A01D
2A
2
1
5
6
16
3
CT
M2
M1
MR
Electrode Connections
Coil Connections
ROSEMOUNT MODEL
8712U TRANSMITTER
Disconnect
This is a pulsed dc
magnetic flowmeter. Do
not connect ac power
to the flowtube or to
terminals1and2of
the transmitter,or
replacement of the
electronics board will
be necessary.
TABLE B-13. Fischer and Porter
Model 10D1465 and 10D1475 Flowtube
Wiring Connections
Rosemount
Model 8712U
Fischer and Porter
Model 10D1465 and
10D1475 Flowtubes
1M1
2MR
3
19 3
18 1
17 2
