Installation
APPLYING POWER
All magnetic flowmeter system connections must be completed before
power is applied to the system. Check the flowmeter connections
between flowmeter and flowtube to be sure they are correct. Check the
connections between the power supply and the system to be sure they
are correct. Apply power to the transmitter.
SOFTWARE
INSTALLATION
Once the magnetic flowmeter system is installed and communication is
established, the transmitter should be configured for basic functions to
complete the installation. You may perform these functions with the
LOI (Section 3 Local Operator Interface) or HART Communicator
(Appendix A HART Communicator). Specific instructions regarding
these functions are provided in Section 4 Device Software
Functions.
Basic software values must be set to complete installation:
• tube calibration number
•tube size
•units
• analog output range
• in-process calibration (Model 8712U and other manufacturers’
flowtubes only)
If your application of the magnetic flowmeter system involves more
advanced functions such as multidrop or pulse output, additional
configuration steps may be required to enable full functionality. See
Section 4 Device Software Functions.
See Safety Messages on page 2-1 for complete warning information.
