Rosemount 8712C - Page 71

A-3
HART Communicator
TABLE A-1. HART Fast Key Sequences
Function HART Fast Key
Analog Output 1, 1, 3
Auto Zero Trim 1, 2, 4, 4
Auxiliary Output 1, 4, 3, 3
Base Time Unit 1, 3, 2, 2, 4
BaseVolUnit 1,3,2,2,2
Basic Setup 1, 3
Burst Mode Control 1, 4, 3, 5, 3
BurstOption 1,4,3,5,4
Calibration 1, 2, 4
Calibration Number 1, 3, 6
Coil Current
(8712U Only)
1, 4, 1, 7
Coil Drive Frequency 1, 4, 1, 3
Configure Outputs 1, 4, 3
Construction Material 1, 4, 5, –
Control Status 1, 4, 4, 4
Conversion Number 1, 3, 2, 2, 3
D/ATrim 1,2,4,1
Damping 1, 3, 7
Date 1, 4, 5, 5
Descriptor 1,4,5,3
Detailed Setup 1, 4
Device ID 1, 4, 5, 6
Device Information 1, 4, 5
Device Setup 1
Diagnostics and
Service
1, 2
Electronics Trim 1, 2, 4, 3
Flow Rate 1, 1, 1
FlowRateUnits 1,3,2,1
Flowtube S/N 1, 4, 5, 7
Flowtube Tag 1, 4, 5, 8
Gross Total 1, 1, 4, 1
HART Output 1, 4, 3, 5
Line Size 1, 3, 5
Loop Test 1, 2, 2
LowFlowCutoff 1,4,4,1
LRV
(Lower Range Value)
1, 3, 4
LSL
(Lower Sensor Limit)
1, 4, 1, 5
Manufacturer 1, 4, 5, 1
Max % Limit 1, 4, 4, 6
Message 1,4,5,4
Net Total 1, 1, 1, 2
Number of Samples 1, 4, 4, 5
Function HART Fast Key
Number Preambles 1, 4, 3, 5, 2
Percent of Range 1, 1, 2
Poll Address 1, 4, 3, 5, 1
Process Variables 1, 1
Pulse Output 1, 1, 5
PulseOutputScaling 1,4,3,2,1
Pulse Output Test 1, 2, 3
Pulse Width 1, 4, 3, 2, 2
PV 2
PV AO 3
PV LRV 4
PVMinSpan 1,4,1,6
PV URV 5
PV Units 1, 3, 2
Reset Totalizer 1, 1, 4, 6
ReverseFlowEnable 1,4,3,3,1
Reverse Total 1, 1, 4, 3
Review 1, 5
Rev Number 1, 4, 5 –
Scaled D/A Trim 1, 2, 4, 2
Self Test 1, 2, 1, 2
Self Test/Status 1, 2, 1
Signal Processing 1, 4, 4
Special Units 1, 3, 2, 2
Start Totalizer 1, 1, 4, 4
Stop Totalizer 1, 1, 4, 5
Tag 1, 3, 1
Time Limit 1, 4, 4, 7
Totalizer 1, 1, 4
Transmitter Gain
(8712U Only)
1, 4, 1, 8
Tube Gain (8712U Only) 1, 4, 1, 9
Universal Trim
(8712U Only)
1, 2, 4, 5
URV
(Upper Range Value)
1, 3, 3
User Defined
Flow Unit
1, 3, 2, 2, 5
User Defined Vol Unit 1, 3, 2, 2, 1
USL
(Upper Sensor Limit)
1, 4, 1, 4
View Status 1, 2, 1, 1
Write Protect 1, 4, 5, 9
Zero Flow Enable 1, 4, 3, 3, 2
