Rotax 912 Series Installation Manual

d04923.fm
INSTALLATION MANUAL
BRP-Powertrain
Effectivity: 912 Series
Edition 2/Rev. 0
73-00-00
page 25
August 01/2012
3.2.5) Technical data
General note See Fig. 12.
Connecting nip-
ple
Connecting nipple (2) of drainage line:
Manifold pres-
sure
Provide connection to take readings of manifold pressure (3).
Temperature sen-
sor
Provide connections for temperature sensor (4):
Connecting nip-
ple
Connecting nipple (5) of float chamber venting lines:

WARNUNG
NOTICE
Utilize the complete slip-on length. Secure hoses by
suitable screw clamps or by crimp connection.

WARNUNG
NOTICE
If the engine has been installed without employment of
the optional ROTAX engine frame which includes also
support of the airbox, than provide an appropriately
support (6) for the airbox.
Outside dia. 6 mm (1/4‘‘)
Slip-on length Max. 17 mm (11/16‘‘)
Outside dia. 6 mm (.24 in.)
Slip-on length Max. 17 mm (.67 in.)
Outside dia. 6 mm (1/4‘‘)
Slip-on length Max. 17 mm (11/16‘‘)

Rotax 912 Series Specifications

General

Redline	5800 rpm
TBO	2000 hours
Displacement	1211 cc
Bore	79.5 mm
Stroke	61 mm
Power Output	80 hp (59.6 kW)
Compression Ratio	9.0:1
Fuel Type	Avgas 100LL
Ignition System	Dual electronic ignition
Fuel System	Fuel Injected
Oil System	Dry sump
Engine Type	4-cylinder, horizontally opposed, 4-stroke
