INSTALLATION MANUAL
BRP-Powertrain
Effectivity: 912 Series
Edition 2/Rev. 0
75-00-00
page 1
August 01/2012
Chapter: 75-00-00
COOLING SYSTEM
General note The shape, size and position of the radiator(s) depends mainly on the
space available in the aircraft.
When correctly installed in the aircraft, the optionally available BRP-Pow-
ertrain radiator has enough cooling capacity to keep within the standard
specified operating limits. The flow resistance of the radiator coolant is
correctly adjusted to the cooling system. The tube size must be sufficient.
The size , shape, orientation of all cooling components must not compro-
mise the engine cooling under all operation conditions.
Table of con-
tents
This section of the Installation Manual contains system description, oper-
ating limits and requirements for the aircraft engine cooling system.
Subject Page
Cooling system
System description
Operating limits
Coolant types
Page 3
Page 3
Page 5
Page 7
Checking the efficiency of the cooling system
Determination of operating limits, Coolant and nec-
essary modification on radiator installation
Page 11
Page 13
Requirements on the cooling system
Connecting size and position of connection
Feasible location of radiator, expansion tank, over-
flow bottle
Page 15
Page 16
Page 19
General notes for the cooling system
Coolant capacity
Cooling air duct
General notes on the cooling air ducts
Data for optional components of cooling system
Page 23
Page 24
Page 25
Page 26
Page 27
