d04922.fm
INSTALLATION MANUAL
BRP-Powertrain
Effectivity: 912 Series
Edition 2/Rev. 0
72-00-00
page 1
August 01/2012
Chapter: 72-00-00
ENGINE
Introduction
Table of contents This section of the Installation Manual contains views of the aircraft
engine, technical data and installation dimensions of the engine.
WARNUNG
NOTICE
Certification in accordance with the latest regulations,
such as FAR or EASA, must be carried out by the air-
craft or fuselage manufacturer.
Subject Page
Engine components, engine views, cylinder designation
Side view
Front view
Top view
Page 3
Page 3
Page 4
Page 5
Technical data
Weight
Installation dimensions
Centre of gravity of engine and standard accesso-
ries
Moments of inertia
Page 7
Page 7
Page 8
Page 8
Page 8
Operating limits
Deviation from the apparent perpendicular
Page 9
Page 9

Table of Contents
