INSTALLATION MANUAL
BRP-Powertrain
Effectivity: 912 Series
Edition 2/Rev. 0
24-00-00
page 11
August 01/2012
2.4.2) Assembly of the flat pin terminal
General note See Fig. 6.
NOTE: One each cable grommet (1) and flat pin terminal (2) are
supplied loosely packed.
Special tools The following special tools and equipment are necessary for fitting the
Faston connector.
Procedure Assembly of the flat pin terminal
NOTE: Faston connector and insulation sheath of the old version
are available as spare part. See also SI-912-013, latest is-
sue.
NOTE: The pin holder must not be pressed with excessive force.
Part number Description
n.a. MOLEX Crimping pliers 64016-0035
n.a. MOLEX Disassembly total 63813-1500
Step Procedure
1 Strip cable (3) as required.
2 Install the cable grommet (1) in correct position and direction (A).
3 Use suitable crimping pliers (4) to fit the fasten connector (B).
4 The rubber grommet is held by the secondary crimp.
5 Push the faston connector in the corresponding slot (4) of the connector recep-
tacle until it is locked in place (C).
6 Check for tight fit.
7 Press the pin holder (white) downwards using the long nose pliers.
