Rotax 912 Series - Page 152

d04926.fm
INSTALLATION MANUAL
BRP-Powertrain
Effectivity: 912 Series
Edition 2/Rev. 0
78-00-00
page 4
August 01/2012
Graphic
Exhaust spring.
It is also recommended to fill the springs with high heat silicone for addi-
tional damping of vibrations.
Fig. 2 08326
approx. 10 mm (.4 in)
stretch
Safety wire
