Fig. 14 08900
Part Function
1 Oil cooler
2 M22x1.5 hex. nut
3 Gasket ring 14.2/18/2
4 Nipple 13.2/9.5
5 M18x1.5/M14x1.5 screw socket
6 Bent socket assy.
7 M14x1.5 angular tube
8 Hose nipple with cap nut
9 3/4-16 UNF/M14x1.5 screw socket
