SAME SILVER 100.4 - Page 105

Fig. 77 - Fit the head vapour breather pipe and the rear
deflector;
Fig. 79 - Install the engine fan assembly;
Fig. 81 - Install the thermostarter;
Fig. 78 - Install the front pulley along with damping flywheel
on SILVER 100.6. The hub should be centred onto the shaft.
Then tighten the securing screws to the torque specified on
page 90. Apply pulley to hub;
Fig. 80 - Fan assembly;
Fig. 82 - Install the fuel pump and the fuel filters and when
required the fuel prefilter. Fit the fuel system lines;
engine
assembly
1
105
