Pressure relief valve and FLOW DIVIDER for 8-way auxiliary spool valve
Fig. 9 - Section through 8-way spool valve.
A - Flow divider
B - Pressure relief valve.
NOTE : The 8-way auxiliary spool valve incorporates a FLOW DIVIDER A which ensures that oil can
be delivered at a constant flow rate of between 3 and 42 l/min to the 2-way kickout section (first valve
alongside the flow divider, see B, fig 8).
The flow divider is adjusted by rotating the knob in the direction as arrowed.
NB: Even when the flow divider is shut off by turning the knob fully in the direction marked (-), a residual
flow of oil will continue to reach the valve at a steady rate of 3 l/min.
88
8
systems
auxiliary systems
386
